Product Description:
The LED grille panel light is a state-of-the-art lighting fixture that is rigged with advanced technology to serve as a reliable source of illumination for any space. Sporting a unique architectural design, this light is super thin and an excellent option for anyone looking to achieve a sleek and modern look.
Whether you want to install the LED grille panel light through pendent, mounted, recessed, or T-grid installation methods, it is very easy to do so since it is designed to accommodate different preferences and needs.
Being a smart and flexible choice, this innovative light fixture makes it possible for you to control the light source quantity with ease, thereby giving you the freedom to customize your lighting requirements as needed.
One of the most outstanding features of the LED grille panel light is that it comes with various lighting beam angles that you can choose from. With these options, you can switch up your lighting style to anything from a narrow spotlight to a broad floodlight depending on your preference. Whether you're using the light fixture for residential, commercial, or industrial purposes, its adaptability makes it an excellent option for all.
Features:
The power input voltage of this product can be range from 120VAC to 277VAC, 120VAC to 347VAC or 220VAC to 240VAC. It offers a variety of wattage options including 20W, 30W, 40W and 60W for different lighting applications.
This product provides two light efficiency options: 125Lm/W or 160Lm/W. Customers can select a beam angle from 30°, 60°, 90°, or 120° according to their needs. In addition, the product has a dimmable feature which supports 0-10V (dual channel), Dali 2 or non-dim options.
This product also has adjustable wattage settings and can tune between different CCT (Correlated Color Temperature) options. Customers can choose from CRI (Color Rendering Index) values greater than 80, 90, or 95 according to their lighting requirements. Moreover, the product also provides for a motion sensor and emergency battery pack available.
To summarize, this product offers a wide range of customization options, including power input voltage, wattage, light efficiency, beam angle, dimmable options, CCT settings, CRI values and add-on features like motion sensors and emergency battery packs. It is a versatile solution that can be tailored to fit a variety of lighting needs.
Technical Parameters:
| Application: | Super Market, Office, Commercial Places, Hospital, Gym, Warehouse, Workshop, Shopping Mall |
| Material: | White Powder Painted Steel |
| Lifespan: | 50,000hrs |
| Beam Angle: | 30°,60°,90°,120° |
| Input Voltage: | 120-277VAC / 120-347VAC / 220-240VAC |
| Luminous Efficacy: | 160LM/W(Max) |
| Warranty: | 5 Years |
| Power: | 40W(Max) / 60W(Max) |
| CRI: | >80 >90 >95 |
| Color Temperature: | 3000K / 3500K 4000K / 5000K |
Accessories
Specification:
5.8Ghz C-Band Microwave.
Input Voltage: 12 - 24V DC.
Input Current:≥25ma.
Operation Temperature: -20°c~+ 70°c
Applications:
Super market, office, commercial places, hospital, gym, warehouse, workshop, shopping mall
